- Mobil SHC Aware H Series lubricants are high performance, anti-wear hydraulic oils for modern high pressure hydraulic systems that meet the U.S.
- Environmental Protection Agency (EPA) 2013 Vessel General Permit (VGP) guidelines for "environmentally acceptable lubricants".
- They provide excellent wide temperature range performance above and beyond the capabilities of non-synthetic environmentally acceptable oils.
- Mobil SHC Aware H Series oils are specially formulated from ester base stocks and provide exceptional anti-wear and film strength characteristics necessary for hydraulic systems operating under high load and high pressures.
Specification and Approvals
Property
|
32
|
46
|
68
|
Grade
|
ISO 32
|
ISO 46
|
ISO 68
|
Acute Algae Toxicity, EC50/72h, mg/l, OECD 201
|
>1000
|
>1000
|
>1000
|
Acute Daphnia Toxicity, EC50/48h, mg/l, OECD 202
|
>1000
|
>1000
|
>1000
|
Acute Fish Toxicity, LC50/96h, mg/l, OECD 203
|
>1000
|
>1000
|
>1000
|
Bioaccumulation, Partition Coefficient, Log Pow, OECD 117
|
<3
|
<3
|
<3
|
Density @ 15 C, g/ml, ASTM D4052
|
0.912
|
0.905
|
0.915
|
FZG Scuffing, Fail Load Stage, A/8.3/90, ISO 14635-1
|
11
|
12
|
>12
|
Flash Point, Cleveland Open Cup, °C, ASTM D92
|
185
|
185
|
185
|
Kinematic Viscosity @ 100 C, mm2/s, ASTM D445
|
6
|
8.2
|
10.37
|
Kinematic Viscosity @ 40 C, mm2/s, ASTM D445
|
32
|
46
|
68
|
Pour Point, °C, ASTM D97
|
-54
|
-36
|
-36
|
Rust Test, Sea Water, 24 h @ 60 C, ASTM D665-PROB
|
PASS
|
PASS
|
PASS
|
Shake-Flask Test, CO2 Evolution (Mod. Sturm), %, OECD 301B
|
>60
|
>60
|
>60
|
Viscosity Index, ASTM D2270
|
140
|
140
|
140
|
Applications
Marine controllable pitch propellers (CPP) systems, fin stabilizers, deck equipment, hydraulic systems where spills or leakage could result in adverse environment impact
In systems where readily biodegradable and minimally toxic fluids may be required
Circulation systems containing gears and bearings where mild extreme-pressure characteristics are desired
Systems containing servo-valves
Hydraulic systems operating with oil temperatures in the range of -30C to +100C
Marine and mobile equipment operating in environmentally sensitive areas
Circulation systems operating under mild to moderate service conditions
Industrial hydraulic systems where leaked or spilled fluids could get into plant effluent
Air line oilers and some limited oil-mist generating systems
